Ingersoll Rand 22475362

Original Ingersoll Rand SIERRA air compressors spare parts from AVISTA LLC. We ship WORLDWIDE directly from Ingersoll Rand warehouse. Ingersoll Rand cpn-22475362 VALVE, INLET/BLOWDOWN CD26D SILVER (200KP4) replaces cpn-39911110 VALVE, INLET/BLOWDOWN CD26D (200KP3). Unit Weight 43KG

• Safe control by means of lubricating oil pressure, load switching of the compressor unit without sufficient bearing lubrication is impossible.
• Simple adjustment of the bypass cross-section at the mechanical forced coupling between the load position of the control element and the relief point of the bleed valve.
• Adjustable control points of the pressure relief valve.
• Simple, robust, long-term proven design.
• Low-friction valve guide by means of large-dimension Teflon piston guide.
• Available up to NW 350
